Start Project BriefArchitectural Façades · System specifier guide
Custom architectural screens for privacy, shading, building identity, service concealment and feature façades. This guide turns the visual system family into a controlled project brief by connecting material, geometry, support, finish, evidence and site conditions before production drawings are released.
Laser-Cut Screens should be selected for the job it needs to perform on the building rather than from appearance alone. Typical pathways include Hospitality façades, Civic buildings, Entrances, Privacy screens, Service-area screening.
Record whether the system is primarily cladding, screening, solar control, ventilation, privacy, feature architecture or a combination. That role determines which geometry, support and evidence questions matter most.
Current design pathways can include Custom geometric patterns, Organic and abstract patterns, Folded screen modules, Framed and frameless visual pathways, Pattern density control. The project drawings should define module logic, panel or profile direction, openings, corners, soffits, returns and visible joint intent before fabrication information is finalised.
Large or unusual modules should be reviewed against the actual material build-up, support centres, transport, lifting and installation sequence rather than inferred from an architectural render.
The visible façade element depends on the subframe, brackets, rails, anchors and supporting substrate behind it. Fixing visibility, tolerances, adjustment, thermal movement and replacement access should be considered with the front-facing design.
Structural loads and fixing capacity remain project-specific. Apollo coordinates the supplied system and available technical information; final structural design and local verification remain with the appointed project professionals unless expressly included.
Priority technical checks for this family include Pattern structural integrity, Panel size and gauge, Wind loads, Cut-edge and finish treatment, Frame and fixing design, Public-access and climbability considerations. Any fire, structural, corrosion, bonding, coating or other performance evidence should match the actual material, thickness, assembly and finish being supplied.
Generic supplier certificates should not be transferred to a materially different façade build-up simply because the visible surface looks similar.
Where colour, texture, pattern, joint alignment, curvature or close-range appearance matters, use project samples or mock-ups before the production finish is frozen.
The final release package should coordinate approved drawings, material and finish schedule, panel or profile references, subframe interfaces, fixing logic, delivery sequencing and any project-specific inspection requirements.
